SDTA – for the simultaneous measurement

           of thermal effects

        One Click™ – provides efficient sample

           measurement

        Nanometer resolution – allows very small

           dimensional changes to be measured

        Wide temperature range – from RT to

          1100 °C

        Specifications - TMA/SDTA 2+ LF/1100

        Temperature range       RT to 1100 °C

        Max. sample length        20 mm

        Length resolution       0.5 mm

        Force range      −0.1 to 1 N

        SDTA resolution       0.005 °C

        DLTMA frequencies       0.01 to 1 H  z

          SDTA – for the simultaneous measurement

           of thermal effects

        One Click™ – provides efficient sample

           measurement

       Nanometer resolution – allows very small

          dimensional changes to be measured

        Wide temperature range – from –80 to 600

      Specifications - TMA/SDTA 2+ IC/600

       Temperature range        –80 to 600 °C

       Max. sample length        20 mm

       Length resolution          0.5 mm

       Force range       −0.1 to 1 N

       SDTA resolution          0.005 °C

DLTMA frequencies:0.01 to 1 Hz
